Specifications [ARK-2120L]Part NumberARK-2120L-S6A1EARK-2120L-S8A1E
Processor
CPU
Intel Atom N2600
Intel Atom D2550Core Number
Frequency
1.6 GHz (Dual Core)
1.86 GHz (Dual Core)L2 Cache
1MB
1MB
Chipset
Intel Atom N2600/D2550 + Intel NM10
Intel Atom N2600/D2550 + Intel NM10
BIOS
AMI EFI 16Mbit
AMI EFI 16Mbit
Memory
Technology
DDR3 800MHz
DDR3 1066MHzMax. Capacity
4 GB
4 GB
Socket
1 x 204-pin SODIMM
1 x 204-pin SODIMM
Graphics
Chipset
Intel Atom N2600/D2550
Graphic Engine
DirectX 9 and OpenGL3.0 support Hardware decode H/W acceleration: MPEG2 H/W Decode/Acceleration: H.264/VC1/WMV9
DirectX 9 and OpenGL3.0 support Hardware decode H/W acceleration: MPEG2 H/W Decode/Acceleration: H.264/VC1/WMV9
VGA
Up to 1920 x 1200
Up to 1920 x 1200
HDMI
Supports 1920 x 1200, Max data rate: up to 1.65 Gb/s, Supports HDMI v1.3 Up to 1080p support
Supports 1920 x 1200, Max data rate: up to 1.65 Gb/s, Supports HDMI v1.3 Up to 1080p supportDual Display
Yes, VGA + HDMI
Yes, VGA + HDMI
Ethernet
LAN1
10/100/1000 Mbps Intel 82583V GbE, support Wake On Lan
10/100/1000 Mbps Intel 82583V GbE, support Wake On LanLAN2
10/100/1000 Mbps Intel 82583V GbE, support Wake On Lan
10/100/1000 Mbps Intel 82583V GbE, support Wake On Lan
Audio
Interface
Realtek ALC892, High Definition Audio. Line-out,Mic-in,Line-in
Realtek ALC892, High Definition Audio. Line-out,Mic-in,Line-in
I/O Interface
Serial Port
3 x RS-232 ports, 1 x RS-232/422/485 port with auto flow control
3 x RS-232 ports, 1 x RS-232/422/485 port with auto flow controlUSB Interface
6 x USB ports, USB 2.0 Compliant
6 x USB ports, USB 2.0 Compliant
Other
Digital IO
255 levels timer interval, setup by software
255 levels timer interval, setup by software
Expansion
Mini PCIe
1 x full size Mini PCIe with SIM holder
1 x full size Mini PCIe with SIM holder
Storage
HDD
Supports one SATA 2.5″ HDD Bay (Compatible with 12.5mm height HDD) (Max. Data Transfer Rate 300 MB/s)
Supports one SATA 2.5″ HDD Bay (Compatible with 12.5mm height HDD) (Max. Data Transfer Rate 300 MB/s)SSD
Supports one external CFast socket
Supports one external CFast socket
Software Support
Microsoft Windows
Windows 7 32bit, Windows 7 Embedded 32bit (XP Professional & XP Embedded support by project)
Windows 7, Windows 7 Embedded (XP Professional & XP Embedded support by project)
Power
Power Type
AT/ATX
AT/ATXInput Voltage
12 VDC, ± 10%
12 VDC, ± 10%
Power Adaptor
AC to DC, DC12 V/3 A, 36 W (Optional)
AC to DC, DC12 V/3 A, 36 W (Optional)
Consumption
Typical 8.9 W, Max. 11 W (with Intel Atom D2550 at 1.8 GHz)
Typical 8.9 W, Max. 11 W (with Intel Atom D2550 at 1.8 GHz)
Mechanical
Construction
Aluminum housing
Aluminum housingMounting
Din-Rail mounting, Desk/wall-mounting, VESA mounting
Din-Rail mounting, Desk/wall-mounting, VESA mountingDimensions
264.5 x 69.2 x 133.0 mm (10.41″ x 2.72″ x 5.24″)
264.5 x 69.2 x 133.0 mm (10.41″ x 2.72″ x 5.24″)Weight
2.3 kg (5.07 lb)
2.3 kg (5.07 lb)
Environment
Operating Temperature
With extended temperature peripherals: -20 ~ 60° C (-4 ~ 140° F) with 0.7m/s air flow; With 2.5-inch hard disk 0 ~ 45° C (32 ~ 112° F) with 0.7m/s air flow
With extended temperature peripherals: -20 ~ 60° C (-4 ~ 140° F) with 0.7m/s air flow; With 2.5-inch hard disk 0 ~ 45° C (32 ~ 112° F) with 0.7m/s air flowStorage Temperature
-40 ~ 85° C (-40 ~ 185° F)
-40 ~ 85° C (-40 ~ 185° F)Relative Humidity
95% @ 40° C (non-condensing)
95% @ 40° C (non-condensing)Vibration during Operation
With SSD: 5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis.
With SSD: 5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis.Shock During Operation
With SSD: 50 G, IEC 60068-2-27, half sine, 11 ms duration
With SSD: 50 G, IEC 60068-2-27, half sine, 11 ms duration
Certification
EMC
CE/FCC Class A, CCC, BSMI
CE/FCC Class A, CCC, BSMI
Safety Certifications
UL, CCC, BSMI
UL, CCC, BSMI
