Máy tính công nghiệp không quạt ARK-2230L

Click lấy báo giá tại đây!

Máy tính công nghiệp không quạt ARK-2230L

  • Intel® Celeron® Quad Core J1900 SoC Modular Fanless Box PC
  • Hoạt động liên tục 24/7
  • Bảo hành 24 tháng
Mã: ARK-2230L Danh mục: Từ khóa: ,
your-image

Máy tính công nghiệp không quạt ARK-2230L

Overview

Intel® Celeron® Quad Core J1900 SoC Modular Fanless Box PC

Intel® Celeron® Quad Core J1900 SoC Modular Fanless Box PC

Features

  • Intel® Celeron® J1900 Quad Core 2.0 GHz SoC
  • VGA and HDMI dual independent display
  • 12V lockable DC jack power input
  • 9-36V power module compatible with all-in-one ordering
  • -20 ~ 60 °C extend temperature operating
  • Mini PCIe expansion with SIM holder for communication module
  • mSATA and 1 x 2.5″ SATA storage device
  • Advantech iDoor module compatible
  • Advantech EMIO miniPCIe module compatible with all-in-one ordering
  • Advantech MIOe module compatible with all in one ordering (2 Layers)

Specifications [ARK-2230L]

Part Number ARK-2230L-U0A1E
Processor
CPU
Intel Celeron Processor J1900 Quad Core SoC
Core Number
4
Frequency
2.0 GHz
L2 Cache
2 MB
BIOS
AMI EFI
Memory
Technology
DDR3L 1333 MHz
Max. Capacity
8 GB
Socket
1 x 204-pin SO-DIMM
Graphics
Chipset
Intel Celeron J1900 SoC integrated, 7th Gen. Intel Graphic core
Graphic Engine
DirectX 11.1, OCL 1.2, OGL 3.2; Encode: H.264, MPEG2/4, VC1, WMV9; Decode: H.264, MPEG2
VGA
Up to 2048 x 1152 @ 60Hz
HDMI
HDMI 1.4a for HD video playback, 1080P at 60Hz
Dual Display
Yes, VGA + HDMI
Ethernet
LAN1
10/100/1000 Mbps Intel i210 GbE, support Wake On Lan
LAN2
10/100/1000 Mbps Intel I210 GbE, support Wake on LAN
Audio
Interface
Realtek ALC888S, High Definition Audio. Line-out,Mic-in,Line-in
I/O
Serial port
2 x RS-232 ports, 2 x RS-232/422/485 port with auto flow control
Digital I/O
8bit programmable general purpose input/output
USB
1 x USB 3.0, 4 x USB 2.0
Others
Watchdog timer
255 levels timer interval, setup by software
Expansion
Mini PCIe
1 x full size Mini PCIe with SIM holder
Storage
HDD
Supports one SATA 2.5″ HDD Bay (Compatible with 12.5mm height HDD) (Max. Data Transfer Rate 300 MB/s)
SSD
1 x full size mSATA socket, with USB signal co-lay
Software Support
Microsoft Windows
Windows 10, WES8, Windows 8, WES7, Windows 7
Linux
Support by project
Power
Power Type
ATX
Input Voltage
12 VDC (9 ~ 36 VDC as option)
Power Adaptor
AC to DC, DC12V/5A, 60 W (Optional)
Consumption
Typical 7.3 W, Max. 13.3 W
Mechanical
Construction
Aluminum housing
Mounting
Din-Rail mounting, Desk/wall-mounting, VESA mounting
Dimensions
260 x 44 x 140.2 mm (10.24″ x 1.73″ x 5.52″)
Weight
2.3 kg (5.07 lb)
Environment
Operational Temperature
With extended temperature peripherals: -20 ~ 60 °C (-4 ~ 140 °F) with 0.7m/s air flow, With 2.5-inch hard disk 0 ~ 40 °C (32 ~ 104 °F) with 0.7m/s air flow
Storage Temperature
-40 ~ 85° C (-40 ~ 185° F)
Relative Humidity
95% @ 40° C (non-condensing)
Vibration during Operation
With SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Shock During Operation
With SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration
Certification
EMC
CE/FCC Class B, CCC, BSMI
Safety Certifications
UL, CCC, BSMI



Chính sách bán hàng

  • Bảo hành 24 tháng
  • Miễn phí vận chuyển toàn quốc
  • Miễn phí dịch vụ lắp đặt, tư vấn sử dụng tại Tp. Hồ Chí Minh
  • Miễn phí dịch vụ bảo trì on-site trong vòng 1 năm tại Tp. Hồ Chí Minh (không bao gồm các huyện ngoại thành). Phản hồi trong vòng 24 tiếng kể từ khi nhận được thông báo.
  • Dịch vụ lắp đặt, bảo trì máy tính công nghiệp on-site tại các tỉnh thành khác vui lòng liên hệ để được báo giá.

Máy tính công nghiệp không quạt ARK-2230L

Downloads [ARK-2230L]
