Switch công nghiệp EKI-7629C

• Provides 2 Gigabit Copper/SFP combo port plus 8 Fast Ethernet ports
• SFP socket for Easy and Flexible Fiber Expansion
• Supports Auto Negotiation and Auto MDI/MDI-X
• Supports 4,000 VDC Ethernet ESD protection
• Supports 3,000 VDC surge (EFT) protection for power line
• Provides flexible mounting: DIN-rail, Wall Mounting
• Supports Dual 12 ~ 48 VDC power input and 1 relay output
• Aside from 2 Gigabit fiber optic/copper combo ports, the EKI-7629C comes equipped with 8 x 10/100Base-TX fast Ethernet ports. Traditional RJ-45 ports can be used for uplinking wide-band paths in short distance(< 100m), or the appropriate replaceable SFP module can be used for the application of wide band uploading and long distance transmissions to fit the field request flexibly. Also, the long MTBF (Mean Time Betwen Failures) ensures that the EKI-7629C wii continue to operate until a Gigabit network infrastructure has been established, without requiring any extra upgrade costs. EKI-7629C includes a switch controller that can automatically sense transmission speeds (10/100 Mbps) The RJ-45 interface can also be auto-detected, so MDI or MDI-X is automatically selected and a cross-over cable is not required. All Ethernet ports have memory buffers that support the store-and -forward mechanism, which assures that data can be transmitted properly. Furthemore, the power line of EKI-7629C supports up to 3,000 VDC surge(EFT) protection, which secure equipment against unregulated voltage and make systems safer and more reliable.

Phản hồi trong vòng 24 tiếng kể từ khi nhận được thông báo.

Switch công nghiệp EKI-7629C

• Datasheet (PDF), Manual/ Driver/ BIOS/ FAQ
